Wire for Wire Rope Manufacturers in Delhi

IKon Wires has the manufacturing capability to produce both uncoated and galvanized rope wire, with diameters ranging from 0.25 mm to 5.00 mm. The company’s annual production capacity for these wires is 3,600 metric tonnes. Below are the general properties of these wires:

Chemical Composition of Steel Wire for Ropes:

Element	Carbon	Manganese	Silicon	Phosphorus	Sulfur	Copper	Nickel	Chromium
Percentage	0.35 – 1.00%	0.30 – 0.90%	0.10 – 0.35%	≤0.25%	≤0.02%	≤0.06%	≤0.05%	≤0.05%

Physical/Mechanical Properties:

Diameter Tolerance: Wire diameter and tolerances are maintained in accordance with IS-1835-1976 or as per customer requirements.
Tensile Strength: The tensile strength of the wire is maintained in line with IS-1835-1976 or as per customer specifications.
Torsion Numbers: The torsion numbers of the wires are controlled as per customer specifications or IS-1835:1976.
Reverse Bend Test: This test is conducted as per IS-1716/1835, with the number of reverse bends maintained as per IS-1835:1976.
Wrap Test: The wrap test of the wire is conducted as per IS-1835:1976 or as specified by customers.
Mass of Zinc Coating: The zinc coating weight on the wire surface is maintained as per IS-1835:1976 or as specified by the customer.
Uniformity of Zinc Coating: The uniformity of the zinc coating is checked as per IS-1835:1976/IS-2633 or as specified by the customer.
Adhesion Test for Galvanized: The adhesion of the zinc coating with the steel wire is checked as per IS-1835:1976 or as specified by the customer.

Coil Dimensions & Coil Weight:

Wire Size (mm)	Coil ID (mm)	Coil OD (mm)	Coil Weight (Kgs.)
0.25-0.40	130	260	10-15
0.41-0.78	160	360	15-28
0.79-1.33	290	400	40-80
1.34-1.45	480	600	80-150
1.46-2.80	480	600	100-200
2.81-3.10	480	600	100-200
3.11-4.00	630	900	150-300
4.01-5.00	730	950	200-500
